Runhorse EV Pure Electric Transport Mini Truck - TEV Series|Zog-Txuag & Siab- Muaj peev xwm
Product Overview
Runhorse EV, lub chaw tsim khoom hluav taws xob tshaj lij nrog ntau tshaj 24 xyoo ntawm kev lag luam kev lag luam, txaus siab nthuav tawm TEV Series - ntau lub zog-txuag thiab eco- phooj ywg ntshiab hluav taws xob thauj mini tsheb thauj khoom tsim los rau kev thauj mus los hauv nroog, kawg - mais kev xa khoom, thiab luv luv - tsheb thauj mus los. Tag nrho peb cov khoom muaj ntawv pov thawj nrog EEC/COC, ISO, CCC, thiab EU Tag Nrho -Tsev Tsheb- pom zoo, kom ntseeg tau tias ua raws li cov qauv kev nyab xeeb thoob ntiaj teb. Nrog lub teeb yuag tag nrho -aluminium carriage, hloov tau yooj yim maneuverability, thiab tus nqi{11}} ua haujlwm tau zoo, TEV Series redefines ntseeg tau thiab sustainability nyob rau hauv lub mini tsheb segment.
Core Zoo
1. Zog-Txuag & Eco-Tus phooj ywg
Zero emissions thiab kev siv hluav taws xob tsawg ua rau TEV Series ib qho kev xaiv ib puag ncig. Powered los ntawm siab -kev ua tau zoo lithium hlau phosphate (LFP) roj teeb, nws txo cov pa roj carbon hneev taw thaum txiav cov nqi ua haujlwm tau zoo piv rau cov roj ib txwm muaj - lub tsheb muaj zog.
2. Txhua yam -Aluminium Structure
Tag nrho -aluminium cargo hopper thiab accessories muaj qhov tshwj xeeb ruaj khov, tiv thaiv corrosion, thiab txo lub tsheb hnyav. Qhov kev tsim no txhim kho lub peev xwm thauj khoom, txuas ntxiv roj teeb lub neej, thiab ua kom lub sijhawm ntev - kev ntseeg siab txawm tias xav tau kev ua haujlwm.
3. Yooj yim Maneuverability
Nrog lub vojvoog tig me me, TEV Series yooj yim los tswj thiab taug kev los ntawm txoj kev nqaim hauv nroog, kev lag luam muaj neeg coob, thiab cov chaw thauj khoom nruj. Nws cov qauv tsim sib xyaw ua ke nrog cov kauj ruam ua haujlwm (EPS system) rau kev tsav tsheb du thiab muaj txiaj ntsig zoo.
4. Txaus siab Load Capacity & Ntau
Boasting tus qauv thauj khoom muaj peev xwm ntawm 650kg, TEV Series ua haujlwm txhua hnub logistics xav tau yooj yim. Ntau lub roj teeb kev xaiv muab kev tsav tsheb hloov tau yooj yim, ua kom nws ua tau raws li qhov xav tau ntawm ntau yam kev thauj mus los - los ntawm kev xa khoom hauv nroog luv mus rau kev thauj mus los ntev dua.
5. Nqis -Kev Ua Haujlwm Zoo
Piv rau diesel-powered micro-vans, TEV Series muab kev txuag nyiaj ntau:
Tus nqi hluav taws xob txhua xyoo rau 30,000km: Tsuas yog $ 550 (raws li $ 0.15 / kWh tus nqi hluav taws xob) vs. $ 2,832-$ 3,776 rau tsheb siv roj
Tus nqi tu thiab kho qis (tsuas yog $ 100 / xyoo ntawm qhov nruab nrab)
Lub roj teeb lub neej ntev thiab kev siv tshuab tsawg tsawg txo qhov ntev - cov nqi ua tswv cuab
Technical Specifications
| Yam khoom | 65km/h Version | 80km/h Version |
|---|---|---|
| Tsheb Loj (LxWxH, mm) | 3690x1400x1910(2080) | 3690x1400x1910(2080) |
| Aluminium Cargo Hopper (LxWxH, hli) | 2085×1300×254 | 2085×1300×254 |
| Cargo Box (LxWxH, hli) | 2100x1310x1280 | 2100x1310x1280 |
| Log Base (mm) | 1815 | 1815 |
| Chassis Clearance (hli) | 160 | 160 |
| Pem hauv ntej / nram qab Track (mm) | 1125/1170 | 1125/1170 |
| Ncua hnyav (tsis muaj roj teeb, kg) | 595 | 595 |
| Loading peev (kg) | 650 | 650 |
| Min. Hloov Radius (m) | Tsawg dua lossis sib npaug rau 4.2 | Tsawg dua lossis sib npaug rau 4.2 |
| Hom Tsav | Permanent Magnet Synchronous Tsav | Permanent Magnet Synchronous Tsav |
| Lub cev muaj zog (KW) | 7.5 | 14.8 |
| Sab saum toj ceev (km / h) | 65 | 80 |
| Lub sij hawm acceleration (s) | <15 | <15 |
| Hom roj teeb | Lithium Hlau Phosphate (LFP) | Lithium Hlau Phosphate (LFP) |
| Roj teeb muaj peev xwm (KWh) | 13.4/20.6/27.2 | 20.6/27.2 |
| Tsav Tsheb (km) | 110-140/190-220/240-270 | 170-200/220-250 |
| Qhov System Voltage (V) | 89.6 | 89.6 |
| Charge hom | Tsev Them Nyiaj + AC Chaw Nres Tsheb | Tsev Them Nyiaj + AC Chaw Nres Tsheb |
| Lub sij hawm them nqi (h) | 4-6.5 | 6.5-10 |
| Climbing peev xwm (%) | Tsawg dua los yog sib npaug li 20 | Tsawg dua los yog sib npaug li 25 |
| Pem hauv ntej/Rear Suspension | Pem hauv ntej Independent Suspension / rear qag hom | Pem hauv ntej Independent Suspension / rear qag hom |
| Pem hauv ntej / Tsheb Nres Hom | Disc Brakes + ABS | Disc Brakes + ABS |
| Steering | LHD / RHD (Yeem) | LHD / RHD (Yeem) |
| Lub log | 175/65R14 | 175/65R14 |
| EU Homologation | EEC(L7e-CU) | EEC(L7e-CU) |
Xaiv cov khoom siv
Cold chain box (rau cov khoom noj tshiab, khoom siv kho mob)
Lub thoob khib nyiab
Cov cuab yeej tu txoj kev
Customized cargo daws rau kev lag luam tshwj xeeb
Txog Runhorse EV
SHANDONG RUNHORSE ELECTRIC VEHICLES CO., LTD. yog lub tuam txhab ua lag luam ntawm qis- tsheb hluav taws xob ceev nrog 270,000m² tus qauv tsim qauv. Nruab nrog 4 hnyav- lub luag haujlwm maus taus cov kab ntau lawm, 2 cathodic electrophoresis txheej kab, 3 lub cev vuam kab, thiab ntau yam khoom siv ntsuas siab, peb ua kom cov khoom zoo ib yam thiab muaj peev xwm ntau lawm.
Nrog lub ntiaj teb muaj nyob, peb cov khoom muaj kev ntseeg siab los ntawm cov neeg siv khoom thiab cov neeg sawv cev hauv Tebchaws Europe (Finland, Ltalis, Lub Tebchaws Yelemees, Fabkis, UK, thiab lwm yam), Asia, Africa, North America, South America, thiab Australia. Peb niaj hnub koom nrog kev nthuav qhia thoob ntiaj teb (Canton Fair, UK Show Center, Czech Exhibition, Netherlands Exhibition, thiab lwm yam) los nthuav qhia peb cov kev tsim kho tshiab thiab ntxiv dag zog rau kev koom tes thoob ntiaj teb.
Daim ntawv pov thawj
EU Tag Nrho -Tsheb Hom- Daim Ntawv Pom Zoo
EEC & COC & DOT (Certificate of Conformity)
ISO Certification
CCC (Tuam Tshoj Compulsory Certificate)
Tiv tauj peb
Email: alice@runhorseev.com
Xov tooj: +8615095248565
Chaw nyob: No.3081, Shibali Street, Economic Development Zone, Qingzhou City, Shandong, Suav teb
Lub Vev Xaib: www.runhorseev.com
Facebook: https://www.facebook.com/profile.php?id=61556485636113
Peb zoo siab txais tos cov neeg xa khoom thoob ntiaj teb, cov neeg sawv cev, thiab cov neeg yuav khoom ntau los koom tes nrog peb. Customization cov kev pabcuam muaj los ua kom tau raws li koj cov kev xav tau tshwj xeeb!
